Other - Mueller Mitteltal - TS 3 kompakt

  • 2011
  • 86899 Landsberg / GERMANY
  • Stuerzer


Additional Notes from seller

Registration Date
Unloaded Weight
10900 kg
Laden Weight
48000 kg
235 / 75 R 17,5
dimensions : 3.900 + 3.600 + 4.900 x 2.480/2.520mm

BPW axles

5th wheel load / increase from 15to to 18to

detouchable ramps
rail to hang in the Alu ramps

lowbed construction
lowbed height 440mm
lowbed length by compliance of the total length of 16.500mm ca. 2.235mm with
long inclination
prologation of the platform of 500mm
extension of the 5th wheel platform of 500mm to 3.900mm

wheel recesses
depth ca. 150mm
loading height in the wheel recess ca. 290mm

rail in the platform front hydraulic liftable to cranked height to direct
loading of the platform,
with mechanical lock

5th wheel strengthened platform for concentrated loading
reinforced with ca. 8to. two dimensionally up to ca. 1.000 x 2.000mm

detouchable hydraulic ramps

adapterrails for hang in in the the short Alu-ramps

rear inclincation ath the plattform ca. 800mm lang
5th wheel platform with 45°chamfered edges
